4MP Wide Angle Bullet Camera - Colornight - Mic/Speaker - IP67

Phantom IP Cameras & RecordersSKU: SC-2K43-ICS-F40M

Price:
Sale price$851.45 CAD
Stock:
Sold out

Description

Overview

This 4MP wide angle bullet camera provides sharp, high definition images in daylight or nighttime color settings. The camera has two 4.0mm fixed lenses. Its maximum resolution is 3840*1080 at 25 fps and supports Ultra 265 video compression technology, which assures savings in bandwidth and storage. Its double lens splicing technology is adopted to realize the horizontal viewing angle of 160.00°±10° and colorhunter technology ensures 24-hour full-color images . It also features human body detection.

Features

  • High quality image with 4MP, 1/2.9"CMOS sensor
  • 4MP (3840*1080)@25fps(Human Body Detection off); 4MP (3840*1080)@20fps(Human Body Detection on)
  • The double lens splicing technology is adopted to realize the horizontal viewing angle of 160.00°±10°
  • Ultra 265, H.265, H.264, MJPEG
  • Support Human Body Detection Colorhunter technology ensures 24-hour full-color images
  • Alarm:1 in/1 out
  • Audio: 1 in/1 out
  • Built-in speaker and dual mics
  • Support 256 GB micro SD card
  • 12V DC/PoE power supply

        Application

        The typical application for most security cameras networks is to connect the IP cameras to a NVR/DVR for simplified playback and additional storage space. Alternatively you can use an IP cameras as a standalone camera and not part of a network by connecting it directly to a POE switch and save the recording on a micro SD card.

        NVR Setup



        Standalone Camera Setup

        Specifications

        Camera
        Image Sensor 1/2.9″, 4.0 megapixel, progressive scan, CMOS
        Minimum Illumination Colour: 0.0005 lux (F1.0, AGC ON)
        Shutter Auto/Manual, 1 ~ 1/100000s
        Adjustment angle

        Pan: 0° ~ 360°
        Tilt: 0° ~ 90°
        Rotate: 0° ~ 360°

        S/N >56dB
        WDR DWDR
        Lens
        Lens Type

        2 * 4.0mm@F1.0

        Iris Fixed
        Angle of View (H)

        160.00°±10°

        Angle of View (V)

        43.22°

        Angle of View (O)

        180.13°±10°°

        DORI
        DORI Distance Lens: 4.0m
        Detect: 64.3m
        Observe: 25.7m
        Recognize: 12.9m
        Identify: 6.4m



        Illuminator
        LED Distance

        Up to 30m (98ft)

        LEDs Number 2
        LED On/Off Control Auto/Manual
        Video
        Video Compression Ultra 265, H.265, H.264, MJPEG
        H.264 code profile Baseline profile, Main profile, High profile
        Frame Rate Main Stream: 4MP (3840*1080), Max 25fps(Human Body Detection off)
        Sub Stream: 1920*540, Max 25fps
        Video Bit Rate 128 Kbps~16 Mbps
        U-code Support
        ROI
        Up to 8 areas
        OSD Up to 8 OSDs
        Privacy Mask Up to 4 areas
        Video Stream Double streams
        White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
        Digital Noise Reduction 2D/3D DNR
        Smart IR Supported
        Flip N/A
        Dewarping N/A
        HLC Supported
        BLC Supported
        Defog Digital Defog
        Events
        Basic Detection Human Body Detection ,motion detection, tampering alarm, audio detection
        General Function Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication
        Audio
        Audio Compression G.711
        Audio Bitrate 64 Kbps
        Two-Way Audio Supported
        Suppression Supported
        Sampling Rate 8KHz
        Storage
        Edge Storage Micro SD, up to 256GB
        Network Storage ANR, NAS(NFS)
        Network
        Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS, SSH
        Compatible Integration ONVIF (Profile S, Profile G), API, SDK
        User/Host Up to 32 users. 3 user levels: administrator, operator and common user
        Security Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
        Client EZStation
        EZView
        EZLive
        Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
        Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+

        Interface
        Audio I/O Input: impedance 35kΩ; amplitude 2V [p-p]
        Output: impedance 600Ω; amplitude 2V [p-p]
        Alarm I/O 1/1
        RS485 N/A
        Built-In Mic Built-in two mics
        Built-In Speaker Supported
        WIFI N/A
        Network 1 * RJ45 10M/100M Base-TX Ethernet
        Video Output N/A
        Certification
        EMC CE-EMC
        FCC
        Safety CE LVD
        CB
        UL
        Environment CE-ROHS
        Protection IP67
        IK10
        General
        Power DC 12V±25%, PoE (IEEE 802.3af)
        Power consumption: MAX 6.5W
        Power Interface Ø 5.5mm coaxial power plug
        Dimensions
        (Ø x H)
        273× 130 × 76mm (10.7” × 5.1” × 3.0”)
        Weight 0.95kg (2.09lb)
        Working Environment/Storage Environment -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)

        -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
        Surge Protection 4KV
        Reset Button Supported
