This bi-directional 10/100/1000Mbps singlemode to multimode media converter allows communication between singlemode and multimode fiber optic cable networks. It can support a total distance of 2km over a SC multimode cable and 20k over a SC singlemode cable.
| Physical Characteristics | ||
|---|---|---|
| Color | Black | |
| Dimensions | 94mm x 70mm x 26mm (L x W x H) | |
| Housing | Metal | |
| Operating Temperature | 0Ā°C ~ 70Ā°C | |
| Relative Humidity | 5% to 90% (non-condensation) | |
| Wavelength | Singlemode:1310nm Multimode: 1310nm | |
| Power | ||
| Power Supply | DC 5V 1.25A | |
| Connectors | ||
| Multimode Connector | SC | |
| Singlemode Connector | SC | |
| Performance | ||
| Media Supported | Singlemode Fiber (8.3/125um, 8.7/125, 9/125um, 10/125um) Multimode Fiber (50/125um, 62.5/125um, 100/140um) | |
| Referenced Transmission Distance | Dual-Fiber Singlemode - 20km Dual-Fiber Multimode - 2km | |
| Data Forward Rate | 10Mbps, 100Mbps, 1000Mbps | |
| Features | Supports Full Duplex and Half Duplex Transmission | |
| Certifications | ||
| CE | Compliant | |
| FCC | Compliant | |
| RoHS | Compliant | |
| Packaging Information | ||
| Package Quantity | 1 | |
| Product Weight | 0.85 lbs [0.03kg] | |
| Warranty Information | ||
| Warranty | 1 Year | |
