This USB 3.1 cable consists of a USB type-C male on one end and a USB Micro-B male on the other end. It is capable of transferring data at 10Gbps and is typically used to connect USB 3.1 peripherals as well as charge and sync USB Type-C mobile devices. USB 3.1 is backwards compatible with previous generation USB devices and is also compatible with Thunderbolt 3 ports.
| Physical Characteristics |
| Color |
Black |
| Connector Plating |
Nickel Plated |
| Contact Plating |
Gold Plated |
| Cable Diameter |
4.5 mm |
| Wire Gauge |
30AWG (data) / 24AWG (power) |
| Jacket Material |
PVC - Polyvinyl Chloride |
| Strain Relief |
Molded |
| Connector(s) |
| Connector A |
9-pin USB 3.1 Type-C SuperSpeed Male |
| Connector B |
9-pin USB 3.1 Micro-B SuperSpeed Male |
| Performance |
| Rating |
USB 3.1 SuperSpeed Gen 2 |
| Speed |
10 Gbps |
| Compatibility |
Backwards Compatible Previous Generation USB |
| Power |
3 Amp |
| Support |
DisplayPort, 4-Channel Audio, Thunderbolt 3, PCI Express |
| Environmental |
| RoHS |
Yes |
| Reach |
Yes |
| Conflict Minerals |
Yes |
| Packaging Information |
| Package Quantity |
1 |
| Warranty Information |
| Warranty |
Limited Lifetime |
| 1.5ft |
3ft |
| 0.06 lbs |
0.12 lbs |
