Description
This cable is primarily used in the assembly of duplex fiber patch cords used in server rooms, data centers and other point to point indoor applications.
| Physical Characteristics | |
|---|---|
| Color | Aqua |
| Fiber Optic Type | Zipcord 2.0 Multimode 50/125um |
| Fiber Core Diameter | 50.0 micron ± 2.0 micron |
| Bandwidth Range | @850 > 3500 MHz/km @1300 > 500 MHz/km |
| Attenuation Range | @850nm 2.3dB/km @1300nm 0.6dB/km |
| Maximum Tensile Load | Short Term, N 450 Long Term, N 200 |
| Minimum Bending Radius | Load 40mm Unload 20mm |
| Fiber Count | 2C |
| Tight Buffer Diameter | 0.9 micron ±0.05 |
| Cable Diameter | 2mm |
| Fire Rating | LSZH |
| Uniformly Distributed | Kevlar |
| Operating Temperature | -40°C ~ +75°C |
| Environmental | |
| RoHS | Yes |
