Description
This DB9 serial cable consists of a DB9 male on both ends. It is commonly used in serial RS-232 data applications.
|
Physical Characteristics
|
||
|---|---|---|
| Color | Beige/Black | |
| Number of Conductors | 9 Conductors | |
| Wire Gauge | 28AWG Stranded | |
| Jacket Material | PVC - Polyvinyl Chloride | |
| Cable Shielding | 100% Aluminum Mylar Foil Shield | |
|
Connectors
|
||
| Connector A | DB9Ā Female | |
| Connector B | DB9 Female | |
|
Pin Out
|
||
| DB9 Female - DB9 Female | ||
| 1 + 6 - 4 | ||
| 2 - 3 | ||
| 3 - 2 | ||
| 4 - 1 + 6 | ||
| 5 - 5 | ||
| 7 - 8 | ||
| 8 - 7 | ||
| Shell - Shell | ||
|
Environmental
|
||
| RoHS | Yes | |
|
Packaging Information
|
||
| Package Quantity | 1 | |
| Product Weight | 0.3 lbs [0.1kg] | |
