OM4 Multimode 50 Micron Indoor AFL (Corning ClearCurve) - OFNR Riser Fiber Bulk Cable (per meter) - 24-strand

OM4 Multimode Bulk CableSKU: BK-F24CP-OM4-R

Fiber Count: Default Title
Price:
Sale price$15.45 CAD
Stock:
In stock

This item does not qualify for free shipping.

Description

This bulk OM4 fiber cable is indoor riser rated and has a tight buffer construction. It is OFNR rated for riser and general inside plant environments. It is ideal for routing between communications closets and equipment rooms.

Features

  • Tested to meet or exceed ICEA-S-83-596, GR-409-I2, CSA 22.2#232, UL 1666.
  • With a riser rating, this cable can be used in riser and general inside plant applications.
  • Compliant to Directive 2002/95/EC (RoHS)
Physical Characteristics
Color Aqua
Fiber Optic Type OM4 50 micron Multimode Riser Indoor Tight Buffered Cable
Fiber Count 24-Strand
Glass Fiber Corning ClearCurve
Sub Unit Diameter 900 Micron
Nominal Diameter 8.4mm (24-Strand)
Tension(Installation) 300 lbs (24-Strand)
Tension(Long Term) 90 lbs (24-Strand)
Bending Radius(Installation) 12.6cm (24-Strand)
Bending Radius(Long Term) 8.4cm (24-Strand)
Operating Temperature -20℃ ~ +70℃
Storage Temperature -40℃ ~ +70℃
Installation -10℃ ~ +60℃
Attenuation Range @850nm 3.0dB/km
@1300nm 1.0dB/km
Bandwidth Range @850nm > 3500 MHz/km
@1300nm > 550 MHz/km
EMBc (MHz-km) 4700
Gigabit Ethernet Min. Link Distance 850nm = 1040
1300nm = 550
10 Gigabit Ethernet Min. Link Distance 850nm = 550
Fire Rating OFNR, FT4
Certification(s)
ETL Yes
c(ETL) Yes
Environmental
RoHS Yes
Reach Yes
Manufacturer Information
AFL Part Numbers CR024C842C01-CRG

Spec Sheets

Download attachment
