1000ft 2C 22AWG Stranded Shielded Control Cable - CMR Riser

Control Bulk CableSKU: BK-CON428-BK

Color: Black
Price:
Sale price$97.60 CAD
Stock:
In stock
Notify me when available


Description

This 2 conductor 22AWG stranded shielded control cable is black and white in color and 1000 feet in length. It is typically used in control panel and automation control applications.

Physical Characteristics
Cable Lengths Available 1000 foot [305m] Pull Box
Color (jacket) Black/White
Number of Conductors 2 Conductors (Red/Black)
Jacket Material 4.0mm PVC - Polyvinyl Chloride
Stranding 7*0.254mm
Jacket Thickness 0.45mm
Insulation Material PVC - Polyvinyl Chloride
Nominal Insulation Diameter 1.9mm
Nominal Insulation Thickness 0.38mm
Wire Gauge 22 AWG
Maximum Voltage 300V
Material (conductors) Oxygen Free Bare Copper
Ripcord Yes
Shielding

Overall Foil Shielded 110%

Drain Wire 7*0.2mm Stranded Tinned Copper
Operating Temperature -20℃ ~ +75℃
Before Tensile Strength >=13.8 Mpa
Aging Elongation >=100%
Aging Condition 100x168ºCxhrs
After Tensile Strength >=85%Mpa of unaged
Aging Elongation >=50% of unaged
Cold Bend No Crack (-20±2º Cx4hrs)
Approvals
c(ETL)us Compliant
ISO 9001 Compliant
ISO 14001 Compliant
ISO 45001 Compliant
Environmental
RoHS Compliant
REACH Compliant
Packaging Information
Package Quantity 1 Pull Box
Product Weight 22.53 lbs
